How Technology is Driving the Democratization of ADAS

Today's ADAS (advanced driver-assistance systems) functions do more than reduce the risk of injuries during a crash. Many features, such as autonomous braking, collision avoidance, and the ability of a vehicle to determine whether a lane change is possible, are designed to help avoid accidents altogether.

ADAS features, only offered to drivers when purchasing a new vehicle as embedded solutions, first appeared as options on high-end luxury vehicles. Unfortunately, to date, it hasn’t been economically feasible for all cars to have all ADAS technologies. But carmakers and Tier-1 suppliers are striving to make driving-assistance features available in as many cars as possible. This means that more vehicles need to be capable of cost-effectively sensing, processing, and acting on real-time data (Fig. 1).

1. The influx of information coming into the car underscores the need for SoCs to quickly and efficiently manage multilevel processing in real time, all while operating within the system's power budget.

Making these systems affordable is important as it enables more market penetration and brings the system advantages to consumers more rapidly. The good news is that ADAS has become more widespread across multiple price points and car models.

Sponsored Resource:

Making ADAS technology more accessible in vehicles

AAA examined 2018 model year vehicles to identify the percentage of ADAS technology that comes standard. According to AAA, at least one ADAS feature was available in 92.7% of new vehicle models in the United States in 2018.

AAA found the following three features to be the most prevalent:

Automatic emergency braking (AEB) (30.6%)—the list of vehicles offering this technology is quickly expanding; at present, 20 OEMs are committed to adding AEB to their vehicle lineup.
Lane-keeping assistance (13.9%)
Adaptive cruise control (11.8%)

Other common driver-assist features include FCW (forward collision warning); PD (pedestrian detection); BSW (blind-spot warning); and APA (advanced parking assist).

The result is that motor vehicles are becoming much safer. According to a recent study by General Motors and the University of Michigan Transportation Research Institute in Ann Arbor, vehicles with lane-keeping assist and lane-departure warning reduced lane-departure-related crashes by 20% (Fig. 2). In addition, rear-end collision rates in vehicles with both FCW and AEB were 46% lower than those without these systems. The study further showed that having a backup camera along with other systems reduced backup crashes by 81%.

2. After comparing the crash instances involving vehicles with and without active safety features, the study showed that certain features evaluated had an impact in preventing the types of crashes the features were designed to help prevent or mitigate. (Source: UMTRI/GM)

Cameras, Radar, and LiDAR

Most ADAS safety features are comprised of sensors such as cameras, radar, LiDAR, ultrasonic and infrared systems as well as a number of actuators. By combining an advanced sensor suite with a central electronic control unit (ECU), functions such as adaptive cruise control, traffic-sign recognition, lane-change assist, lane-keeping assist, and traffic-jam support all can be enabled.

Camera-based systems give drivers visual cues to make them more informed and aware of their surroundings. Multiple cameras (four to six) placed around the car provide a 360-degree view.

Front-camera systems can use a mono- or stereo-camera setup. The main advantage of a mono camera is that it can be installed at low cost and the degree of freedom for the installation location is high. These cameras are expected to be widely used as parking sensors due to their increasing penetration in economy cars, especially in emerging economies.

More sophisticated stereo cameras are useful to obtain 3D information. These visual systems measure distance and lateral position to various objects such as pedestrians, bicycles, and vehicles with higher accuracy. However, stereo-camera systems are more expensive compared to mono-camera solutions. All camera systems suffer from the fact that they’re easily affected by poor weather conditions.

An important advantage of radar over cameras is that radar is resistant to nighttime conditions, or when visibility is bad due to weather. Radar is useful for vehicular applications such as parking assist, lane-change assist, and car safety applications like autonomous braking and collision avoidance. Radar also is utilized as a sensor to detect pedestrians and other cars.

Radar systems have become mainstream in recent years as they have become highly compact and affordable. The primary limitation in radar has been angular resolution and with it the ability to distinguish between static objects close together. That shortcoming is rapidly being addressed, though. For example, TI’s AWR1243 imaging radar solution can distinguish between static objects 0.6 degrees apart with a 350-m object detecting range.

Light detection and ranging (LiDAR) is a sensing method that detects objects and maps their distances. The technology works by illuminating a target with a laser pulse and measures the characteristics of the reflected return signal, helping vehicles "see" other objects like cars, pedestrians, and cyclists.

Since it was first introduced into automotive applications, the cost of LiDAR has dropped precipitously. An early model used by companies developing self-driving prototypes cost about $75,000—clearly not practical for mass production. But the cost has come down. At the 2020 Consumer Electronics Show (CES), for instance, suppliers showed off LiDAR with a range of 100 meters and a cost of $100. While not as powerful as top-of-the-line LIDARs, which boast ranges of 200 meters or more, the more compact low-cost model—smaller than a deck of playing cards—allows automakers to easily embed it into their vehicles (Fig. 3).

3. Market research firm Yole projects a 12.1% CAGR for automotive visual systems from 2018 to 2024. In a typical vision-based system camera, data is captured via a serial interface and is then sent to a vision-processing hardware engine. (Source: Yole Développement)

Greater Processor Capability

More cameras, radar, and LiDAR with higher resolution all translate into stringent requirements for high-performance processing. Processors for ADAS applications need to be able to combine megabytes of visual or other sensor data to produce an interpreted environment for the car. To make ADAS applications affordable in low- and mid-end vehicles, it’s important to have a cost-effective processing solution.

If nothing else will convince you that available SoC solutions can scale from more simple cases (fewer sensors, lower resolutions) to the most complex cases without compromising basic ADAS features, the newest members of Texas Instruments’ Jacinto 7 processor family should (Fig. 4).

4. Jacinto 7 processors enable mass-market adoption of automotive ADAS and gateway technology. (Source: Texas Instruments)

The TDA4VM SoC for ADAS enables critical features for automated parking, such as surround view and image processing for displays. Its 8-Mpixel front-camera support enables the car to see farther and clearer in all driving conditions. This SoC supports four to six 3-Mpixel cameras while also fusing other sensors such as radar, LiDAR, and ultrasonic systems on one chip. TI's new processor also uses just 5 to 20 W of power, eliminating the need for active cooling.

The TDA4VM provides high-performance computing for both traditional and deep-learning algorithms with a high level of system integration. This leads to scalability and lower cost for automotive platforms supporting multiple sensors in centralized ECUs or as standalone sensors.

An Inevitable Migration

Implementing ADAS features on low- or mid-level cars isn’t easy. And yet recently, a number of ADAS applications that only appeared in high-end cars have trickled down to the low- and mid-level vehicles.

With governments focusing on safety as a top priority, if industry doesn’t take the lead, sooner or later mandatory safety equipment standards will be imposed. For example, in 2018, some 25,000 people died on European Union roads and 135,000 were seriously injured. In response, in April 2019, the EU Parliament passed legislation making it mandatory—starting in May 2022 for new models and May 2024 for existing models—to have an emergency braking system as well as an emergency lane-keeping system on passenger cars and light commercial vehicles (it was already compulsory for trucks and buses).

To make ADAS available across the board for new model cars, the technology will have to be made even more affordable. But as we have shown, the mainstream use of ADAS in modern-day cars is being made possible by reducing the size and complexity of individual components, such as sensors, as well as integrating more processing functions into comprehensive IC platforms. These trends are complementary because smaller, less-expensive components are needed to build larger systems affordably.

What’s more, in terms of reining in ADAS costs, solutions are accommodating an open software-development methodology, making it possible to reuse the resulting code and preserve efforts made in development and testing.

Considering the headwind of slowing demand for new cars challenging automotive markets, the democratization of ADAS is likely to be accomplished gradually over a period of years. But make no mistake: The race to develop advanced driver assistance systems is on. Major vehicle original equipment manufacturers and Tier-1 suppliers are accelerating development efforts to get ahead in the race and gain a share of a market estimated to be US$30.0 billion in 2019 and projected to reach US$134.9 billion by 2027, representing a CAGR of 20.7% (Fig. 5).
